K-level proudly presents the KLL-012 Line Laser, a cutting-edge line laser level designed for professionals who require ultimate precision and versatility in construction, renovation, and interior design projects. As part of our advanced laser level series, the KLL-012 stands out with its 4-line projection capability, providing 360° coverage for complex layouts with unmatched accuracy.

The KLL-012 line laser level features highly visible green laser beams, offering 4x brighter visibility compared to traditional red lasers—perfect for brightly lit job sites and large-scale projects. With self-leveling technology and a ±0.1mm/m accuracy, this 4 line laser level ensures flawless alignment for tasks such as floor tiling, ceiling installations, and wall framing.

KLL-012 Line Laser Wide Applications
Whether you’re a contractor, electrician, or DIY enthusiast, the KLL-012 adapts to tasks like:

Wall and floor alignment

Drop ceiling installation

Framing and grading

HVAC and electrical work

Need a Solution?
K-level provides Consulting Services for surveying equipment. Contact Us for bulk orders or technical support!

1.Dual Laser Options for Every Need

KLL-012 RED (635nm): Ideal for indoor applications, this red laser line offers excellent visibility in low-light conditions, perfect for tasks like drywall installation, tiling, and cabinetry.

KLL-012 GREEN (520nm): Brighter and more visible than red lasers, the green beam excels in outdoor or well-lit environments, making it the go-to choice for construction layout, landscaping, and large-scale projects.

2.Self-Leveling for Effortless Accuracy
The KLL-012 Line Laser features a pendulum self-leveling system with a ±3° range, ensuring precise leveling and plumb lines in seconds. If the surface is uneven, an out-of-level alarm alerts you for quick adjustments.

3.Durable & Job-Site Ready
Built to withstand tough conditions, the KLL-012 line laser level has an IP54-rated housing for dust and water resistance, along with shock-absorbing materials to protect against accidental drops.

4.Long Battery Life & Easy Operation
Powered by rechargeable lithium batteries, the KLL-012 line laser level delivers extended runtime, while its one-button control simplifies operation for seamless workflow efficiency.

KLL-012 line laser level Specifications

Model No.	KLL-012R	KLL-012G
Light Source	Red Beam	Green Beam
Laser Wave Length	635nm	520nm
Laser Diode	10mw	30mw
Laser Safety Class	Class 2
Leveling Range:	±3°
Leveling Time	<5 sec
Leveling Accuracy	±3mm/10m
Power	3x AAA Alkaline Battery
Operation Time	About 8h	About 6h
Operation Temperature	-10℃-+50℃
Mounting Thread	1/4″-20
Waterproof	IP54
